Based on this assumption, the reader is familiarized with S7-200 Micro/Win software (developed by Siemens Automation) to show the reader how the software could be used to edit, run and finally how to debug a program in hand. Since this is a self-teach manual, it is assumed that reader may not have any access to a PLC or instructor, to discuss any problems. It explains most basic to intermediate and advance instructions through many worked-out examples and explanation of the solutions. This E-book provides both fundamental and cutting-edge coverage on PLCs. In PLC programming this means writing many small programs and using some kind of simulator software to test programs' functionality. I There is a quotation which was originally stated by Confucius, I would like to present it here as a very practical statement on how the human mind opproaches the learning process:Īll this means is the best way to understand anything is to get your hands on it and actually experiment with it. The update for the CP5711 is available for downloading in Entry ID: 39722731.There is a quotation which was originally stated by Confucius, I would like to present it here as a very practical statement on how the human mind opproaches the learning process: I hear, and I forget I see, and I remember I do, and I understand - Confucius All this means is the best way to understand anything is to get your hands on it and actually experiment with it. Now can you access the S7-200 CPU with the CP5711 in STEP 7 MicroWin via the PPI interface? Then confirm the settings with "OK" and then close the "Set PG/PC Interface" tool with "OK". Set the "Transmission Rate" parameter to 9.6 kbps the "Profile" parameter to Universal DP/FMS. Open the parameter settings by clicking on the "Properties." button. Select the "CP5711 PROFIBUS" for "Interface Parameter Assignment Used". The CP5711 is then installed automatically. Slot the CP5711 into the USB port of the computer. This is then available in STEP 7 MicroWin.įurther steps are required to parameterize an S7-200 CPU via the integrated PPI interface.

#STEP 7 MICRO WIN S7 200 INSTALL#

Select the "SIMATIC NET PC Software 2008" product for installation.Ĭomplete the installation of the SIMATIC NET PC software.Īfter successfully completing the installation of the SIMATIC NET PC software, install the CP5711. In this case, start the "Setup.exe" program in the main directory of the SIMATIC NET CD. 30s), then your computer's Autostart function is not enabled.

If this dialog does not appear after a certain time (approx.

Insert the SIMATIC NET CD in your computer's CD or DVD drive. Proceed as follows to install SIMATIC NET PC software. This is included in the delivery package of the CP5711.

#STEP 7 MICRO WIN S7 200 DRIVERS#

The drivers are supplied with the SIMATIC NET PC Software Edition 2008 SP1 and later.
